What is Serial? The concept of serial communication is simple. The serial port sends and receives bytes of information one bit at a time. This is slower than parallel communication, which allows the transmission of an entire byte at once; however, it is simpler and can be used over longer distances. Backyard Baseball 2007 Download Pc. For example, the IEEE 488 specifications for parallel communication state that the cabling between equipment can be no more than 20 meters total, with no more than 2 meters between any two devices; serial can extend as much as 1200 meters. Typically, serial is used to transmit ASCII data.

The cables that carry this data (other than 'the' serial cable) and the computer ports they plug into are usually referred to with a more specific name, to reduce confusion. Keyboard and mouse cables and ports are almost invariably serial—such as PS/2 port and Apple Desktop Bus and USB. The cables that carry digital video.

Communication is completed using 3 transmission lines: (1) Ground, (2) Transmit, and (3) Receive. Since serial is asynchronous, the port is able to transmit data on one line while receiving data on another. This is referred to as Full-Duplex transmission. Other lines are available for handshaking, but are not required. The important serial characteristics are baud rate, data bits, stop bits, and parity. For two ports to communicate, these parameters must match: • Baud rate is a speed measurement for communication.
